The versatility of this equipment is one of its most notable features. Thanks to its motorized Zoom system, the Aqua Eris 280Z becomes a true all-rounder, allowing you to adjust its light beam from 5º to 40°, making it a smart choice for any application that requires advanced light control. Additionally, its IP65 weather resistance makes it a reliable option even in harsh conditions for use in fixed installations or for lighting rental companies, events, theaters, and more. In summary, the Aqua Eris 280Z is much more than just a light source. It’s a high-end lighting tool that combines exceptional performance, flexibility, precise color reproduction, and weather resistance. Whether you’re lighting a stage, an outdoor event, or an architectural installation, this LED PAR is the perfect companion to make your ideas shine. FEATURES LIGHT SOURCE

• LED: 7 x 40W RGBA
• Luminance at 1 meter (all LEDs):
• Closed at 5º: 123,000 Lux
• Open at 45º: 8,490 Lux

OPTICS

• Zoom: 5º to 40º
• Motorized zoom linear movement
• Lens type: Plano-convex honeycomb design

COLOR SYSTEM

• Color mixing: RGBA
• Color temperature adjustment: 3,200K to 7,000K
• Color macro generating common direct colors

DYNAMIC EFFECTS

• 16-bit resolution control
• Special features: White fading channel in any color

CONTROL

• Protocol: DMX512, RDM
• DMX channels: 4, 5, 8, or 11 DMX channels
• RDM: Remote Device Management for monitoring and remote configuration
• High-resolution OLED display with 4 buttons for projector parameter control

ELECTRONICS

• Electronic dimmer with linear adjustment from 0 to 100%
• 4 dimmer curves: Linear, square, inverse square, and S-curve
• Strobe: 1 to 25 f/s

ELECTRICAL

• Power supply: AC 100-240V 50/60Hz
• Max power consumption: 300W

CONNECTORS

• Power input and output: PowerCON TRUE 1 16A
• DMX input and output: 3-pin XLR

PHYSICAL

• Environmental protection range: IP65
• Cooling: Active and silent operation
• Mounting and installation: Dual yoke support for secure hanging and easy ground installation

BODY

• Robust weather-resistant construction
• Color: Black

ENVIRONMENTAL

• Temperature range: -10º to +45º

DIMENSIONS AND WEIGHT

• Projector dimensions: 306 x 183 x 433 mm
• Package dimensions: 595 x 390 x 285 mm
• Projector weight: 11.60 kg
• Weight with packaging: 13 kg

CERTIFICATIONS

• CE
• RoHS

PACKAGE CONTENT

• 1 Aqua Eris 280Z LED PAR projector
• 1 PowerCon/Schuko power cable
• 1 User manual

IDENTIFICATION

• Brand: Triton Blue
• Model: Aqua Eris 280Z
• EAN Code: 8474407180153

About RDM Function RDM (Remote Device Management) is an enhancement to the DMX512 lighting protocol developed by USITT (United States Institute for Theatre Technology) that enables two-way communication between lighting consoles and RDM-compatible devices via a standard DMX line. Key points about RDM:

• Bidirectional Communication: RDM allows lighting devices and DMX controllers to communicate both ways, meaning devices can send information back to the lighting console.
• Configuration and Control: With RDM, it’s possible to configure, control, and manage lighting devices remotely, simplifying system setup and maintenance.
• Required Compatibility: To use RDM, both the DMX controller and lighting devices or accessories must be RDM-compatible and meet the protocol’s standards. In summary, RDM is a valuable feature in lighting control that enhances efficiency and system management by allowing bidirectional communication and control over a standard DMX line.
